57.5W Triple output power supply +5V/+12V/-5V T-60A

Features:

1. Full range AC input

2. Protection: over voltage, over current, short circuit protection

3. Heat from the cold

4. 100% full-load burn-in test

5. High quality and low price

Specification:

Model number	T-60A			T-60B			T-60C
Model number	CH1	CH2	CH3	CH1	CH2	CH3	CH1	CH2	CH3
DC Output Voltage	5V	12V	-5V	5V	12V	-12V	5V	15V	-15V
Output Voltage Error	± 2%	± 6%	± 6%	± 2%	± 6%	± 6%	± 2%	± 6%	± 6%
Rated Output Current	5A	2.5A	0.5A	5A	2.5A	0.5A	5A	2A	0.5A
Output Current Range	0.5-5A	0.2-2.5A	0.1-0.5A	0.5-5A	0.2-2.5A	0.1-0.5A	0.5-5A	0.2-2.5A	0.2-0.5A
Ripple and Noise	80mVp-p	100mVp-p	80mVp-p	80mVp-p	100mVp-p	100mVp-p	80mVp-p	100mVp-p	100mVp-p
Inlet Stability	± 0.5%	± 1%	± 0.5%	± 0.5%	± 1%	± 0.5%	± 0.5%	± 1%	± 0.5%
Load Stability	± 1%	± 4%	± 1%	± 1%	± 4%	± 1%	± 1%	± 4%	± 1%
DC Output Power	57.5W			61W			62.5W
Efficiency	72%			72%			72%
Adjustable Range for DC Voltage	CH1: +10, -5%			CH1: +10, -5%			CH1: +10, -5%
AC Input Voltage Range	85~264VAC 47~63Hz; 120~370VDC
Input Current	2A/115V 1A/230V
AC Inrush Current	Cold-Start Current 18A/115V 36A/230V
Leakage Current	＜1mA/240VAC
Overload Protection	105%~135% Type: Cut Output, Reset: Auto Recovery
Over Voltage Protection	CH1: 5.75~6.75
High-temperature Protection	................................
Temperature Coefficient	± 0.03% /°C (0~50°C) ON+5V
Start, Rise, Hold time	300ms, 50ms, 80ms
Vibration	10~500Hz, 2G 10min/1 cycle, a total of 60 minutes, Each axes
Withstand Voltage	Input and Output Interval: 1.5KVAC, Input and Enclosure: 1.5KVAC, Output and Enclosure: 0.5KVAC
Isolation Resistance	Input and Output Interval: Input and Enclosure, Output and Enclosure: 500VDC/100M Ohms
Working Temperature and Humidity	-10°C~+60°C, 20%~90%RH
Dimension	1599838 mm
Weight	0.55kg

Dimension unit:mm
