60W Quad output power supply +5V/+15V/-5V/-15V Q-60C

Features:

1. Full range AC input

2. Protection: over voltage, over current, short circuit protection

3. Heat from the cold

4. 100% full-load burn-in test

5. High quality and low price

Specification:

Model number	Q-60B				Q-60C
Model number	CH1	CH2	CH3	CH4	CH1	CH2	CH3	CH4
DC Output Voltage	5V	12V	-5V	-12V	5V	15V	-5V	-15V
Output Voltage Error	± 2%	± 6%	± 5%	± 5%	± 2%	± 5%	± 5%	± 5%
Rated Output Current	5.5A	2A	0.5A	0.5A	5.5A	1.5A	0.5A	0.5A
Output Current Range	0-5.5A	0-2A	0-0.5A	0-0.5A	0-5.5A	0-1.5A	0-0.5A	0-0.5A
Ripple and Noise	100mVp-p	120mVp-p	100mVp-p	120mVp-p	100mVp-p	120mVp-p	100mVp-p	120mVp-p
Inlet Stability	± 0.5%	± 1%	± 0.5%	± 0.5%	± 0.5%	± 2%	± 0.5%	± 0.5%
Load Stability	± 0.5%	± 4%	± 1%	± 1%	± 0.5%	± 4%	± 1%	± 1%
DC Output Power	60W				60W
Efficiency	70%				72%
Adjustable Range for DC Voltage	CH1: +10, -5%				CH1: +10, -5%
AC Input Voltage Range	90~264VAC 47~63Hz; 120~370VDC
Input Current	2A/115V 0.8A/230V
AC Inrush Current	Cold-Start Current 18A/115V 36A/230V
Leakage Current	＜1mA/240VAC
Overload Protection	105%~135% Type: Cut Output, Reset: Auto Recovery
Over Voltage Protection	115%~135%
High-temperature Protection	................................
Temperature Coefficient	± 0.03% /°C (0~50°C) ON+5V
Start, Rise, Hold time	800ms, 20ms, 60ms
Vibration	10~500Hz, 2G 10min/1 cycle, a total of 60 minutes, Each axes
Withstand Voltage	Input and Output Interval: 1.5KVAC, Input and Enclosure: 1.5KVAC, Output and Enclosure: 0.5KVAC
Isolation Resistance	Input and Output Interval: Input and Enclosure, Output and Enclosure: 500VDC/100M Ohms
Working Temperature and Humidity	-10°C~+60°C, 20%~90%RH
Dimension	1599838 mm
Weight	0.56kg

Dimension unit:mm
